Specifications of power supply unit:
Model CR6C
Specification 50A 75A 100A # 150A # 250A #
Input voltage                                        3   V 220.346 220.346 220.346 220.346 220.346
380.415 380.415 380.415 380.415 380.415
Input power KVA 7 10 15 20 30
Working voltage(No load) V 100 100 100 150 250
High voltage V 140 or 250 140 or 250 140 or 250 140 or 250 140 or 250
Min. ON TIME µS 1 1 1 1 1
Min. OFF TIME µS 1 1 1 1 1
Max. Cutting speed mm3/min 480 720 1050 1500 2500
Best surface finish µmRa. 0.2 0.2 0.2 0.2 0.2
Min.Electrode wear rate % 0.3 0.3 0.3 0.3 0.3
Weight kg 210 248 360 490 700
# One extra power unit. Continuing improvement will allow the maker to modify the design or specification without notice.
Specification for machine unit:
Model Unit CNC1160
Table travel(X axis) mm 1100
Table travel(Y axis) mm 600
Quill travel(Z1 axis) mm -
Work head travel(Z2 axis) mm 450
Work table dimensions(LxW) mm 1250x800
Distance between plate and table mm 500-1000
Work tank inner dimensions(WxDxH) mm 2000x1300x700
Max. capacity of dielectric fluid Liter 1810
Max. electrode weight kg 300
Max. workpiece weight kg 3500
Machine unit dimensions(WxDxH) mm 3400x3350x3200
Machine unit weight kg 5500
